Ultra Abdominal Crunch

Ultra Abdominal Crunch

G7-S51
Action Specific Grips provide greater comfort and minimal point pressure.

Add to Wishlist

Email to a friend

Category: Single Station

Description

Description

FEATURES

• Curved back pads for full muscular contraction and comfort

• Self-aligning handles adjust to accommodate a variety of users

• Dual-supported pivoting design fosters natural abdominal crunch motion

• Action Specific Grips provide greater comfort and minimal point pressure

• Elbow pad wear covers improve upholstery performance in high contact areas

• The optional Intelligent Training Console features Endurance, Build and Strength programs to give members a guided training experience specific to their goals

Action Specific Grips™

Ergonomically designed, function specific handles reduce stress on contact points to enhance user comfort.

Incremental Weights

Incremental weights are easily accessible from the seated position. Numeric selection allows users easy reference for future use.

Electronic Rep Counter

Integrated system tracks repetitions, activity time, and rest time for a simplified workout experience.

Intelligent Training Console (Optional)

When you choose Ultra Series with Intelligent Training Console, you’ll get a digitally connected, guided experience.

ADJUSTMENTS

User adjustment range 7 position seat

Machine assisted user adjustments Spring assisted seat

Color coded pivots & points of adjustment Yes

FRAME & CABLES

Available frame colors Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

Frame finish Proprietary two-coat powder process

Cable transmission Internally lubricated cables & fittings

Machine anchoring Independent machine hold down brackets

Integrated leveling system Yes, top-down leveler

INTELLIGENT TRAINING CONSOLE (OPTIONAL)

Progression Based Programming Yes

Stored user settings Yes – Seat Settings and Bluetooth HR

Demo Video Yes

Dual User Sign-In Yes

Workouts Manual, Endurance, Build, Strength*, E-Lifts*

Personal Trainer Portal Compatible Yes

Netpulse Compatible Yes

Workout Tracking Network Compatible Yes

Web Connectivity Yes

WiFi Yes

Display Feedback Sets, Reps, Rest Time, Total Weight Lifted

Ethernet Port Yes

Bluetooth Heart Rate Only

User-defined Multi-language Display English, German, French, Italian, Spanish, Dutch, Portuguese, Chinese, Japanese, Korean, Swedish, Finnish, Russian, Arabic, Turkish, Polish, Welsh, Basque, Vietnamese, Somali, Danish

Lift to Start Yes

FitTouch™ Technology Yes

Display Type 25.7 cm / 10.1″ class touchscreen LCD

Asset Management Compatible Yes

Facility Communication Portal/Calendar No

CSAFE Ready-FitLinxx™ Certified No

USB Port No (service only)

Assembled Dimensions As assembled on Ultra weight stack – 153 cm / 60.2″

Power Requirements 100v-240v – 50/60Hz AC

Shipping Weight 7.8 kg / 17.2 lb

TECH SPECS

Overall “static” dimensions (L x W x H) 139 x 121 x 147 cm / 54.6″ x 47.5″ x 57.9″

Overall “in-use” dimensions (L x W x H) 139 x 121 x 147 cm / 54.6″ x 47.5″ x 57.9″

Product weight 290 kg / 640 lbs

Shipping weight 338 kg / 746 lbs

Rep counter machine usage tracking Service mode tracks total machine reps and hours of use

Rep counter battery life Approximately 3 years

Rep counter power supply 2 AA batteries

USER AMENITIES

Front placards Muscle call outs, exercise specific stretching, start & finish exercise illustrations, proper machine adjustments, color-coded machine identification

Rear placards Color-coded machine identification, exercise specific stretching

Placard color coding Green (core)

Rep counter Electronic counter displays reps, exercise time and rest time

Personal storage Two tactile storage mats, personal device cradle and towel hook

Action Specific Grips Exercise specific grips improving feel, function and form during use

Contoured seat Yes

Elbow Wear Covers Yes
